DB-50CNC Double Head Hydraulic Pipe Bending Machine Product Introduction

一、 Product Overview
The equipment supports free switching between automatic and manual operation modes, adapting to small-batch customization and large-batch standardized processing needs. Its double bending heads can run independently or realize synchronous symmetric bending, and the rotatable bending head structure meets the processing of complex geometric pipe parts. It adopts a stable dual-cabinet structure, with easy adjustment of the bending shaft center; the distance between double heads is servo-driven for adjustment, realizing fast, precise and low-noise positioning, and the built-in enhanced head locking system automatically locks the head in place to improve operation stability. Equipped with a triple clamping design, it avoids workpiece deformation to the greatest extent, and fully complies with CE and ISO9001 certifications with a complete safety protection system. The equipment can bend 2/4/6/8 tubes at one time (depending on tube size and bending radius), compatible with various metal materials and cross-section pipe types.

二、 Main Technical Parameters
Maximum bending capacity: Φ50×2.0mm;
Maximum bending radius: R300mm;
Double bending center spacing range: 500-3600mm (customizable);
Maximum pressure: 14MPa;
Main motor power: 7.5Kw;
Spacing adjustment servo motor power: 1.82Kw;
Bending servo motor power: 5.52Kw;
Equipment dimensions: 5000×1000×1300mm


三、Core Advantages
1. High production efficiency: Dual-head independent/synchronous operation + one-time multi-pipe bending, symmetric bending design ensures high consistency of mass-produced symmetric parts.
2. Precise and flexible control: Servo-driven double head distance adjustment with high repeatability; rotatable bending head and adjustable shaft center meet complex part processing needs.
3. Super stable operation: Dual-cabinet structure + enhanced head locking system + triple clamping design, multi-dimensional guarantee of bending precision and no workpiece deformation, low-noise operation.
4. Reliable configuration & international compliance: Adopts well-known brand core components with long service life; compliant with CE and ISO9001, meeting international quality and safety standards.
5. Strong adaptability: Compatible with various metal materials and cross-section pipes/bars, flexible adjustment for different processing scenarios.
四、Application Fields
Relying on high efficiency, precision and strong adaptability, the equipment is widely used in automotive and rail transportation (oil pipes, brake pipes, structural pipes), hardware manufacturing (metal hardware pipe parts, decorative pipes), mechanical equipment manufacturing (construction machinery structural pipes), sanitary ware and HVAC (forming pipes, copper/aluminum pipeline parts), effectively improving product quality consistency and production efficiency, and realizing the automated upgrading of pipe processing production lines.
